Sediment Water Filters:  Sand, Silt, Turbidity, Rust
Carbon Filter
Residential, Commercial & Irrigation Sediment Filtration Series
Well Water or City Water Sediment, Sand, Silt, & Turbidity Removal Systems

SAND FILTERS: Customers experiencing high sediment, silt, sand, and turbidity please see our no-maintenance RDWS-NS sand sediment filtration systems. Superior media filtration technology based on a rare natural mineral that is highly processed and refined. It's unique properties allow it to radically alter the performance and cost of media filtration. The hardness, stability and micro-porous character makes it a perfect filtration media for virtually every application in the water treatment industry.

Features:
- High capacity filtration throughout the entire media bed depth provides more than twice the capacity of multimedia filtration.
- High Service Flow 3-4 times that of multimedia with superior filtration.
- Long lasting media (>5 years) not consumed in the process.
- Simple NO ROUTINE filter replacement maintenance, NON-chemical periodic backwash keeps the media clean and operating efficiently.

Applications Include:
RO Pretreatment superior SDI reduction
Cooling Towers unequalled Turbidity removal
Municipal Water Treatment, pressure and gravity filters higher flow, lower pressure drop and superior filtration performance
Wastewater Polishing exceptional TSS removal
Precipitated metals removal
Carwash reclaim and recycling
Irrigation

High Filtration Performance: 3-5 Micron Sediment, Sand, Turbidity, Suspended Solids Removal

Chemical Free - Maintenance Free - User Friendly

Easy installation for the Do-It-Yourselfer, Plumber, or Contractor - Only 3 Connections

Designed for High Flow Rates, Irrigation, Light Commercial to Industrial Water Treatment

NSF Certified Components & Filtration Media

Filter Tank & Control Valve made in the USA & assembled in the USA

Self Cleaning - Automatic Backwashing - Space Saving Single Tank

RDWS-NS-125-10 Sediment, Sand, Silt, Turbidity & Rust - Designed For Whole House & Irrigation Well Water Filtration
Iron Max Iron Filter

IN STOCK: YES - FREE DELIVERY

RDWS-NS-125-10
High Flow Sediment Filter

Retail Price: $1,695.00
Lowest RainDance Online Price: $1,095.00


Model # RDWS-NS-125-10
System Function High Performance Rust, Sediment, Sand, Turbidity Water Treatment System
Dimensions 10" dia. x 65" ht.
Maximum Flow Rate 10 gpm
Minimum Flow Rate 7 gpm
Maximum Removal Capacities From 0.3 - 1ppm (mg/L) Ferrous & Ferric Iron & Rust Staining
From 3 to 5 Micron Sediment, Sand Turbidity

The RDWS-NS "Smart Filtration Series" Built To Withstand Seasonal Well Water Changes
Minimum/Maximum Pressure 30/100 psi
Power 110v
Required Maintenance No Routine Replacement Filters
Automatic Self-Cleaning System
System Weight 150 lbs
Plumbing Size 3/4", 1" or 1.25"
*Please specify when ordering
Bypass Valve Yes, Included
Protective Tank Jacket Yes, Included
Installation Instructions Yes, Included
Tech Support Yes, Included

RDWS-NS-125-12 Sediment, Sand, Silt, Turbidity & Rust Filter - High Flow Whole House & Irrigation Water Treatment
Iron Max Iron Filter

IN STOCK: YES - FREE DELIVERY

RDWS-NS-125-12
High Flow Sediment & Turbidity Filter

Retail Price: $1,795.00

Lowest RainDance Online Price: $1,195.00


Model # RDWS-NS-125-12
System Function High Performance Sediment, Sand, Turbidity & Rust Water Treatment System
Dimensions 12" dia. x 65" ht.
Maximum Flow Rate 15 gpm
Minimum Flow Rate 10 gpm
Maximum Removal Capacities From 0.3 - 1ppm (mg/L) Ferrous & Ferric Iron & Rust Staining
From 3 to 5 Micron Sediment, Sand Turbidity

The RDWS-NS "Smart Filtration Series" Built To Withstand Seasonal Well Water Changes
Minimum/Maximum Pressure 30/100 psi
Power 110v
Required Maintenance No Routine Replacement Filters
Automatic Self-Cleaning System
System Weight 175 lbs
Plumbing Size 1" or 1.25"
*Please specify when ordering
Bypass Valve Yes, Included
Protective Tank Jacket Yes, Included
Installation Instructions Yes, Included
Tech Support Yes, Included
RDWS-NS-125-14 Sediment, Sand, Silt, Turbidity Filter - High Volume Irrigation & Whole House Treatment
Commercial Iron Max

IN STOCK: YES - FREE DELIVERY



RDWS-NS-125-14
High Flow Sediment Filter

Retail Price: $2,595.00

Lowest RainDance
Online Price: $1,995.00


Model # RDWS-NS-125-14
System Function High Performance Sediment, Sand, Turbidity Water Treatment System
Dimensions 14" dia. x 72" ht.
Maximum Flow Rate 21 gpm
Minimum Flow Rate 15 gpm
Maximum Removal Capacities 3-5 Micron Sediment, Sand Turbidity
From 0.3 - 1ppm (mg/L) Rust & Iron
Minimum/Maximum Pressure 30/100 psi
Required Maintenance No Routine Replacement Filters
Automatic Self-Cleaning System
System Weight 275 lbs
Plumbing Size 1" or 1.25"
Bypass Valve Yes, Included
Installation Instructions Yes, Included
Tech Support Yes, Included
RDWS-NS-125-16 Commercial Sediment, Sand, Silt, Turbidity Filter - High Volume Irrigation & Whole House Treatment
Commercial Iron Max

IN STOCK: YES - FREE DELIVERY

RDWS-NS-125-16
Commercial Sediment Filter

Retail Price: $2,995.00

Lowest RainDance
Online Price: $2,295.00



Model # RDWS-NS-125-16
System Function High Performance Sediment, Sand, Turbidity Water Treatment System
Dimensions 16" dia. x 72" ht.
Maximum Flow Rate 28 gpm
Minimum Flow Rate 20 gpm
Maximum Removal Capacities 3-5 Micron Sediment, Sand Turbidity
From 0.3 - 1ppm (mg/L) Rust & Iron
Minimum/Maximum Pressure 30/100 psi
Required Maintenance No Routine Replacement Filters
Automatic Self-Cleaning System
System Weight 375 lbs
Plumbing Size 1" or 1.25"
Bypass Valve Yes, Included
Installation Instructions Yes, Included
Tech Support Yes, Included



Commercial High Flow Sediment Filters

Model # Tank Size Pipe Size Service
Flow Rate
Backwash
Flow Rate
RDWS-NS-18
Get Quote Now
18" Diameter
65" Height
1.5" 33gpm 25gpm
RDWS-NS-21
Get Quote Now
21" Diameter
62" Height
1.5" 50gpm 30gpm
RDWS-NS-24
Get Quote Now
24" Diameter
72" Height
2" 60gpm 45gpm
RDWS-NS-30
Get Quote Now
30" Diameter
72" Height
2" 98gpm 60gpm
RDWS-NS-36
Get Quote Now
36" Diameter
72" Height
2" 140gpm 90gpm
